THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 12
Feb 19/04
1K18
APPENDIX 1
(5) Disconnect the autopilot harness.
(6) Remove the capstan cover and cable guards (4) by removing the retaining screws (4).
(7) Remove the bolt, nut, and washer securing the idler pulley to the trim servo baseplate and
mounting bracket and remove the idler pulley components.
NOTE: The idler pulley breaks down into the following components upon removal of the bolt,
above: mounting plate/cable guard assembly, idler pulley, and two washers.
(8) Remove the remaining bolts, nuts, and washers (3 ea.) securing the trim servo to its mounting
bracket and remove the trim servo.
B. Installation
(1) Adjust trim servo clutch torque per Servo Clutch Torque Adjustment, below.
(2) With the capstan cover and cable guards removed, position the trim servo as shown in
Figure 5. Secure with bolts, nuts, and washers (3 ea. - i.e. - aft two and forward left).
(3) Assemble the idler pulley cable guards (3) to the mounting plate with screws (1 ea.) and star
washers (2 ea.). Place the center bolt through the mounting plate/cable guard assembly and
slide a washer over the threaded end and up against the mounting plate. Set the mounting
plate/cable guard/bolt assembly aside.
(4) Drape the slack left trim cable over the servo capstan.
CAUTION: IN STEPS (5) THRU (9), BELOW, USAGE OF LEFT AND RIGHT IS RELATIVE TO
THE VIEW OF THE TECHNICIAN IN THE CABIN BAGGAGE AREA LOOKING AFT,
EXCEPT WHERE AIRPLANE COMPONENT PARTS ARE SPECIFICALLY NAMED.
(5) Place thumb and forefinger on top of the capstan over the trim cable in its groove. Pressing the
trim cable into its groove, slide thumb and forefinger down around opposite sides of the servo
capstan and pull the trim cable slack towards you and to your left.
(6) Holding the trim cable in that position, install the capstan cover and cable guards as shown in
Figure 5.
(7) Hold the idler pulley aft of the trim servo and to the right of the aiplane’s left trim cable. Move
the idler pulley left to the left trim cable and capture the trim cable in the bottom cable groove
on the left of the idler pulley.
(8) Keeping the trim cable in the bottom groove, slide the idler pulley forward along the trim cable,
left of the servo capstan, and bring it approximately to its installed position (See Figure 5). At
this point, the aft portion of the trim cable should be routed left, around the front, and to the
right of the idler pulley and to the left, around the rear, and to the right of the capstan.
(9) Holding the idler pulley in this position, reach down and pull the forward portion of the trim
cable over the idler pulley and seat it in the top cable groove on the idler pulley. The left trim
cable should now be routed as shown in Figure 5.
(10) Place the spacer inside the idler pulley.
(11) Position the mounting plate/cable guard/bolt assembly as shown in Figure 5 and slide the bolt
through the spacer inside the idler pulley.
(12) Place a washer over the bolt end and put the bolt through the trim servo mounting bracket and
baseplate. Secure with a nut and washer, taking care to ensure that the cable guards are
positioned, and the left trim cable is routed, as shown in Figure 5.
(13) Take up the slack in the left trim cable with the turnbuckle and remove the pull ropes.
(14) Rig stabilator trim per Stabilator Trim Rigging and Adjustment, 27-30-00.
