THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 9
Jun 1/03
5H5
91-10-00
Decimal/Millimeter Equivalents of Drill Sizes From 1/2" to No. 80
Size Decimal Millimeter Size Decimal Millimeter Size Decimal Millimeter Size Decimal Millimeter
Equiv. Equiv. Equiv. Equiv. Equiv. Equiv. Equiv. Equiv.
1/2 0.500 12.7000 G 0.261 6.6294 5/32 0.1562 3.9687 51 0.067 1.7018
31/64 0.4843 12.3031 F 0.257 6.5278 23 0.154 3.9116 52 0.0635 1.6129
15/32 0.4687 11.9062 E-1/4 0.250 6.3500 24 0.152 3.8608 1/16 0.0625 1.5875
29/64 0.4531 11.5094 D 0.246 6.2484 25 0.1495 3.7973 53 0.0595 1.5113
7/16 0.4375 11.1125 C 0.242 6.1468 26 0.147 3.7338 54 0.055 1.397
27/64 0.4218 10.7156 B 0.238 6.0452 27 0.144 3.6576 55 0.052 1.3208
Z 0.413 10.4902 15/64 0.2343 5.9531 9/64 0.1406 3.5719 3/64 0.0468 1.1906
13/32 0.4062 10.3187 A 0.234 5.9436 28 0.1405 3.5687 56 0.0465 1.1811
Y 0.404 10.2616 1 0.228 5.7912 29 0.136 3.4544 57 0.043 1.0922
X 0.397 10.0838 2 0.221 5.6134 30 0.01285 3.2639 58 0.042 1.0668
25/64 0.3906 9.9212 7/32 0.2187 5.5562 1/8 0.125 3.1750 59 0.041 1.0414
W 0.386 9.8044 3 0.213 5.4102 31 0.120 3.048 60 0.040 1.016
V 0.377 9.5758 4 0.209 5.3086 32 0.116 2.9464 61 0.039 0.9906
3/8 0.375 9.5250 5 0.2055 5.2197 33 0.113 2.8702 62 0.038 0.9652
U 0.368 9.3472 6 0.204 5.1816 34 0.111 2.8194 63 0.037 0.9398
23/64 0.3593 9.1262 13/64 0.2031 5.1594 35 0.110 2.794 64 0.036 0.9144
T 0.358 9.1281 7 0.201 5.1054 7/64 0.1093 2.7781 65 0.035 0.899
S 0.346 8.7884 8 0.199 5.0546 36 0.1065 2.7051 66 0.033 0.8382
11/32 0.3437 8.7300 9 0.196 4.9784 37 0.104 2.6416 1/32 0.0312 0.7937
R 0.339 8.6106 10 0.1935 4.9149 38 0.1015 2.5781 67 0.032 0.8128
Q 0.332 8.4328 11 0.191 4.8514 39 0.0995 2.5273 68 0.031 0.7874
21/64 0.3281 8.3337 12 0.189 4.8006 40 0.098 2.4892 69 0.029 0.7366
P 0.323 8.2042 3/16 0.1875 4.7625 41 0.096 2.4384 70 0.028 0.7112
O 0.316 8.0264 13 0.185 4.699 3/32 0.0937 2.3812 71 0.026 0.6604
5/16 0.3125 7.9375 14 0.182 4.6228 42 0.0935 2.3749 72 0.025 0.635
N 0.302 7.6708 15 0.180 4.572 43 0.089 2.2606 73 0.024 0.0696
19/64 0.2968 7.5387 16 0.177 4.4958 44 0.086 2.1844 74 0.0229 0.58166
M 0.295 7.4930 17 0.173 4.3942 45 0.082 2.0828 75 0.021 0.5334
L 0.290 7.3660 11/64 0.1718 4.3656 46 0.081 2.0574 76 0.020 0.508
9/32 0.2812 7.1425 18 0.1695 4.3053 47 0.0785 1.9939 77 0.018 0.4572
K 0.281 7.1374 19 0.166 4.2164 5/64 0.0781 1.9844 1/64 0.0156 0.3969
J 0.277 7.0358 20 0.161 4.0894 48 0.076 1.9304 78 0.016 0.4064
I 0.272 6.9088 21 0.159 4.0386 49 0.073 1.8542 79 0.0145 0.3683
H 0.266 6.7564 22 0.157 3.9878 50 0.070 1.778 80 0.0135 0.3429
17/64 0.2656 6.7462
DRILL SIZES AVAILABLE
Drill may be obtained in regular sizes to a 4 inch diameter, and increase in 64ths of an inch. The regular metric drills vary
from 2 to 76mm and increase in 0.5mm variations.
CHART 7
DRILL SIZES
