THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 2
Jun 1/03
2C6
21-20-00
(f) Position blower fan on motor shaft and secure with set screw.
(g) Position hose duct on blower assembly and secure with screws, washers, and nuts. Install
screws with heads inside duct.
(h) Clean old sealant from all surfaces where duct attaches to blower assembly.
(i) Seal all surfaces where duct attaches to blower assembly with Sealant, Airframe and
Window (see 91-10-00, Chart 8).
(4) Installation
(a) Position blower assembly in hangers and retainer. Install washers and screws.
(b) Secure blower assembly to hanger braces nuts, washers, and screws.
(c) Seal all hose joints with Arno No. C-520 wrap tape.
(d) Install inlet and outlet hoses. Secure with clamps.
(e) Ensure master switch is OFF. Connect plug and receptacles to blower.
(f) Check blower for proper operation.
(g) Install access door to aft wall of baggage area. Secure with attaching hardware.
NO
TE: Pin number 1 is at pointed side of plug and receptacle.
CHART 1. BLOWER SYSTEM WIRE COLOR CODES
1482-22-1 Dukes
24 VOLT MOTOR WIRES AIRCRAFT WIRES
Pin Nos. Aircraft Harness Pin Nos.
Ground 1 Green AC26A 1
Low Speed 2 Red AC8A 2
High Speed 2 Orange AC10A 2
To Next Page
