THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 3
Jun 1/03
2C15
21-50-00
CHART 1 (Sheet 1 of 5)
TROUBLESHOOTING AIR CONDITIONING SYSTEM
Trouble Cause Remedy
High discharge pressure. Refrigerant overcharge. Purge excess refrigerant.
Air in system. Check for leaks. Bleed
charge from system.
Evacuate and recharge
system.
Overheated condenser due to Clean bugs and dirt from
blocked air passage. condenser fins. Straighten
bent fins.
Flooded evaporator indicated Check capillary bulb is
by heavy frosting on suction line securely clamped to
and compressor suction service suction line. If capillary
valve. bulb is OK, replace
expansion valve.
Restriction in liquid line from Check for kinked hoses and
condenser. clogged filter.
Low discharge pressure. Refrigerant undercharge. Sight Add refrigerant until
glass shows bubbles or foam. bubbles disappear.
Check system for leaks.
Damaged compressor valves or Replace compressor.
dirt under valves.
Damaged compressor. Worn or Replace compressor.
broken piston or piston rings.
Low suction pressure Low air supply through Repair blower or blower
accompanied by icing evaporator. motor. Clean stoppage
of evaporator. in air ducts.
Very dirty evaporator fins and Clean and flush with water.
coils.
Low suction pressure. Refrigerant undercharge. Moisture Add refrigerant. Install new
(Evaporator not cold enough.) freezing in expansion valve. Valve dryer. Evacuate and
Suction gauge reads vacuum shows frost. recharge.
indicating evaporator lacks
refrigerant. Expansion valve inlet screen Remove screen. Clean with
clogged. Inoperative expansion solvent and replace.
valve. Valve stuck closed or Warm capillary by holding
capillary bulb has lost charge. in hand. If suction pressure
does not change replace
expansion valve.
Restriction in liquid line. Locate restriction and
Restriction will show frost. repair.
