THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 31
Jun 1/03
2D19
21-50-00
Positioning Sanden Compressor Internal Parts
Figure 10
Fabricated Dipstick
Figure 11
30Ëš
4.115 "
0.118 " (3mm) INCREMENTS
TYPICAL FOR
20 NOTCHES
