THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 2
Jun 1/03
2F6
23-50-00
AMMETER
GMA-340
GNS-430
GTX-327
CLOCK
GI-106A
T & B
AS
AG
DG
ALT
VS
OIL TEMP
OIL PRES
CHT
VAC
ELT
FUEL
QUAN
MAN PRES
FUEL FLOW
TACH
EGT
TO GND
(BLK)
AUDIO PANEL
COMM/NAV/GPS
TRANSPONDER
COM1 FROM COM1 ANT
P340P2
NAV1 FROM NAV/GS COUPLER
GPS1 FROM GPS1 ANT
GS1 FROM NAV/GS COUPLER
P327P1
GS
NAV
COM
GPS
GI 106A
NAV
TO TRANSPONDER ANT
J5/P5 TO CO-PILOT CONTROL WHEEL
CIRCUIT BREAKERS
- AUDIO AMP/MKR (5 AMP)
- COM1 (5 AMP)
- NAV1/GPS1 (5 AMP)
- ENCODER (1 AMP)
- XPNDR (3 AMP)
CONNECTOR "SPKR"
TO CABIN SPEAKER PLUG
MIC KEY WIRES TO CONTROL WHEEL
(CW15H22 TO PIN1, CW16H22 TO PIN2)
CONN P350P1 TO AK350 BLIND ENCODER
XPDR INDENT WIRES TO CONTROL WHEEL
(CW7H22 TO PIN1, CW8H22 TO PIN2)
P430P1
P340P1
P430P2
P430P6
P106P1
STANDARD AVIONICS INSTALLATION
(6X SHOWN)
Avionics Installation
Figure 2 (Sheet 1 of 2)
