THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 5
Jun 1/03
2F9
23-50-00
PILOT PA MIC SPKR LEVEL
CO-PILOT PA MIC SPKR LEVEL
AIRCRAFT RADIO SPKR LEVEL
MUSIC 1 MUTE TRIP LEVEL
(NOT USED IN THIS INSTALLATION)
MARKER BEACON AUDIO LEVEL
MARKER BEACON LOW SENSITIVITY
MARKER BEACON HIGH SENSITIVITY
FRONT
(VIEW LOOKING DOWN)
GMA-340 Audio Panel Adjustments
Figure 3
