THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 2
Jun 1/03
2J12
27-20-00
CHART 1
TROUBLESHOOTING RUDDER CONTROL SYSTEM
Trouble Cause Remedy
Lost motion between rudder Cable tension too low. Adjust cable tension.
pedals and rudder.
Linkage loose or worn. Check linkage and tighten
or replace.
Broken pulley. Replace pulley.
Bolts attaching rudder to Tighten bellcrank bolts.
bellcrank are loose.
Excessive resistance to System not lubricated Lubricate system.
rudder pedal movement. properly.
Rudder pedal torque tube Lubricate torque tube
bearing in need of lubrication. bearings.
Cable tension too high. Adjust cable tension.
Pulleys binding or rubbing. Replace binding pulleys
and or provide clearance
between pulleys and
brackets.
Cables not in place on Install cables correctly.
pulleys. Check cable guards.
Cables crossed or routed Check routing of control
incorrectly. cables.
Rudder pedals not neutral Rudder cables incorrectly Check rigging of rudder
when rudder is streamlined. rigged. cables.
Incorrect rudder travel. Rudder bellcrank stop Check rigging of bellcrank
incorrectly adjusted. stops.
Nose wheel contacts stops. Check rigging of nose
wheel stops before rigging
rudder.
Trim control knob moves System not lubricated Lubricated system.
with excessive resistance. properly.
