Piper 6X User Manual

CHAPTER 32 - LANDING GEAR
TABLE OF CONTENTS
SUBJECT SECTION PA
GE GRID NO.
THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 2
Jun 1/03
3E18
32 - CONTENTS
WHEELS AND BRAKES 32-40-00 13F19
Wheels 13F19
Main Wheel Assembly 1 3F19
Removal and Disassembly 1 3F19
Inspection 2 3F20
Assembly and Installation 2 3F20
Nose Wheel Assembly 2 3F20
Removal and Disassembly 2 3F20
Inspection 2 3F20
Assembly and Installation 2 3F20
Repair 33F21
Bearing Cup Replacement 4 3F22
Brakes 43F22
Brake Adjustment and Lining Tolerance 4 3F22
Wheel Brake Assembly 4 3F22
Removal and Disassembly 4 3F22
Cleaning, Inspection and Repair 4 3F22
Assembly and Installation 7 3G1
Hand/Parking Brake Master Cylinder 7 3G1
Removal 7 3G1
Disassembly 7 3G1
Cleaning, Inspection and Repair 7 3G1
Assembly 9 3G3
Installation 9 3G3
Toe Brake Cylinder(s) 10 3G4
Removal 10 3G4
Disassembly 10 3G4
Cleaning, Inspection and Repair 10 3G4
Assembly 10 3G4
Installation 10 3G4
Brake System Leak Check 12 3G6
Bleeding Brakes 12 3G6
Gravity Procedure 12 3G6
Pressure Procedure 13 3G7
After a Unit Has Been Changed 13 3G7
