THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 5
Jun 1/03
4C15
39-20-00
Electrical/Electronic Component Locator
Figure 1 (Sheet 4 of 8)
S
A
E
R
C
N
I
E
34
2
5
1
LANDING
LIGHT
RELAY
BLACK
RED
P2G20
P2H14
BLUE
REGULATOR ASSEMBLY
PITOT HEAT
SENSOR
L3K16
L10S16N
L3C16
L3B16
L10S16N
FWD
UNDER INSTRUMENT PANEL
LEFT SIDE, LOOKING OUTBOARD
