THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 8
Jun 1/03
4C18
39-20-00
Electrical/Electronic Component Locator
Figure 1 (Sheet 7 of 8)
W4B20
W4C20
W5B20
W5C20
VACUUM NO. 1 INOP SWITCH
VACUUM NO. 2 INOP SWITCH
DIODE
P3B4 TO ALTERNATOR SHUNT
P3C4 TO STARTER SOLENOID
BENEATH FORWARD BAGGAGE COMPARTMENT FLOOR
LEFT SIDE, LOOKING DOWN
