COMPONENT LUBRICANT FREQUENCY
1. FLAP TORQUE TUBE BEARING BLOCKS MIL-L-7870 100 HRS
2. FLAP CONTROL ROD END BEARINGS MIL-L-7870 100 HRS
3. FLAP HANDLE PIVOT POINT, LOCK MECHANISM AERO LUBRIPLATE FISKE BROS.
AND TURNBUCKLE END OF AERO SHELL GREASE #7 100 HRS
4. FLAP RETURN AND TENSION CHAINS MIL-L-7870 500 HRS
5. AILERON BELLCRANK PIVOT POINTS MIL-L-7870 100 HRS
6. AILERON CONTROL ROD END BEARINGS MIL-L-7870 100 HRS
7. AILERON BELLCRANK CABLE ENDS MIL-L-7870 100 HRS
Figure l2-6. Lubrication Chart (Control System) (cont.)
12 - 27 - 00
Page - 12 - 21
Reissued: August 1, 1986
1D17
PIPER AIRCRAFT
PA-28-236
MAINTENANCE MANUAL
