COMPONENT LUBRICANT FREQUENCY
1. RUDDER TUBE BEARING BLOCKS FLUOROCARBON RELEASE
AGENT DRY LUBRICANT
MS-122 100 HRS
2. TOE BRAKE CYLINDER ATTACHMENTS MIL-L-7870 100 HRS
3. RUDDER TUBE CONNECTIONS MIL-L-7870 100 HRS
4. BRAKE ROD ENDS MIL-L-7870 100 HRS
Figure 12-6. Lubrication Chart (Control System) (cont.)
12 - 28 - 00
Page - 12 - 22
Reissued: August 1, 1986
1D18
PIPER AIRCRAFT
PA-28-236
MAINTENANCE MANUAL
