b. Select a BKG file. In the dialog box that appears, select OK to import the
BKG file.
Capture
a. Select Capture to access the submenu.
b. From the drop-down options, select PGM or an input source for capture.
c. Select Capture.
d. After an image is captured successfully, select Save to save the captured
image as a BKG file.
Manage LOGO
Apply, export, delete and import LOGO files.
Prerequisites
Before importing a LOGO image, copy the LOGO file (.png, .bmp, .jpg, .jpeg) to
the root directory of a USB drive and insert the USB drive into the USB port on the
front panel of the P20/P10.
Before exporting a LOGO image, insert a USB drive into the USB port on the front
panel of the P20/P10.
Notes
The USB port on the front panel of the P20/P10 does not support USB HUB.
LOGO does not use the layer resources.
The LOGO image is always at the front of the layer order and cannot be resized.
You can change the position of the BKG image.
When you are importing a LOGO file using the event controller or PixelFlow, you
are not able to import LOGO files using the P20/P10.
The total number of BKGs and LOGOs cannot exceed 255 and the total storage
space for BKG and LOGO files is up to 512 MB.
The maximum resolution of a single LOGO file is 512×512 pixels.
Menu Orientation
On the main menu screen, scroll to and select Layer.
