1.4 Symbols used in the manual
The following symbols are used in this manual.
1.5 Terminology list
The table below explains common terms used by Qimarox for the machine.
DANGER
Risk of serious injury to the user if the instructions are not accurately followed.
WARNING
Risk of damage to the machine if the instructions are not accurately followed.
Note
To provide additional information to the user about a task or issue.
Tip
A tip or point of attention for carrying out a task.
Term Definition
supply conveyor The conveyor that delivers product to the infeed conveyor on the machine.
The supply conveyor is not part of the machine.
discharge conveyor The conveyor that discharges products from the machine. The discharge
conveyor is not part of the machine.
assemble Assembly of the machine.
fenced area Area around the machine that unauthorised personnel cannot enter for
safety reasons.
infeed conveyor The supply conveyor puts products on the infeed conveyor. The infeed con-
veyor is part of the machine.
trolley The part that keeps the carrier in straight position during forward direction.
machine The PRORUNNER Mk5.
installation Installation of the machine within a transport system.
product Products transported by the machine.
product carrier The part on which the transported product is resting. This part has the form
of a product carrier. Refer to the description in section 4.2.3 and the
exploded views in chapter 15.
