Exploded views of frame parts
140 UM-PRORUNNER_Mk5-1.2-EN-US
15.6.3 Assembly section parts list - 3
/i
M 1001809 Cover PRmk5 rear 0.75 mm R77 793 x H 684, S235 SV
RAL 9010
N 1000015 Cover PRmk5 front 8 mm sprocket 586 x H 758 plastic, grey
7036
N 1000963 Cover PRmk5 front 8 mm sprocket 586 x H 758 plastic, white
667
N 1001667 Cover PRmk5 front 8 mm sprocket 586 x H 758 plastic, blue
FL29
N 1001805 Cover PRmk5 front 3 mm sprocket 586 x H 758 alu panel,
white (matt)
N 1001830 Cover PRmk5 front 3 mm sprocket 586 x H 758 alu panel,
RAL9006
Assembly section - 2
Item no. 1000144
Pos Article number Description (parts) Notes
Assembly section - 3
Item no. 1000144
Pos Article number Description (parts) Notes
O 1000017 Cover PRmk5 front 8 mm A1475 586 x H 487 plastic, grey
7036
O 1000018 Cover PRmk5 front 8 mm A1725 586 x H 737 plastic, grey
7036
O 1000019 Cover PRmk5 front 8 mm A1975 586 x H 988 plastic, grey
7036
O 1000020 Cover PRmk5 front 8 mm A1250 586 x H 1249 plastic, grey
7036
O 1000021 Cover PRmk5 front 8 mm M1950 586 x H 1949 plastic, grey
7036
O 1000022 Cover PRmk5 front 8 mm S1975 586 x H 914 plastic, grey
7036
O 1000023 Cover PRmk5 front 8 mm S1475 586 x H 414 plastic, grey
7036
O 1000024 Cover PRmk5 front 8 mm S1725 586 x H 664 plastic, grey
7036
O 1000856 Cover PRmk5 front 8 mm 586 x H 1349 plastic, grey
7036
O 1000962 Cover PRmk5 front 8 mm A1475 586 x H 487 plastic, white
667
