UM-PRORUNNER_Mk5-1.2-EN-US 157
Exploded views of product conveyors
16.4.1 Gravity roller infeed parts list
/i
Drive section Package B-01
Item no. 1003925
Pos Quan
tity
Item
number
Description (parts) Notes
A 1 1003060 Conveyor bracket PRmk5
B 9 1003064 Arm t.b.v. rol PRmk5
C 1 1003072 Fastening reflector PRmk5
D 1 1002242 Reflector
E 9 1003106 ROL 40 KUN IL 500
F 9 1003065 Contraplat arm PRmk5
G 4 1003058 Support standard
4 1004269 Support MK5-XL
H 0.5 1004305 Conveyor supports PRmk5 400
I 1 xxxx Coupling piece
J 1 1003068 Fastening photocell PRmk5
K 1 1002097 Photocell
L 2 1003066 Fastening rol PRmk5
M 1 1003062 Bracket rolsupport bi PRmk5
N 1 1003061 Bracket rolsupport bu PRmk5
O 1 1003063 Basis conveyor frame PRmk5
Q 1 1003071 End stop PRmk5
