Qimarox PRORUNNER Mk5 User Manual

Maintenance vertical conveyor
74 UM-PRORUNNER_Mk5-1.2-EN-US
7.8.5 Replace the wheel of the leveler
1. Remove the guide. Refer to section 7.8.4.
2. Loosen the bolt.
3. Replace the wheel (A) of the leveler (B).
4. Replace the bolt and tighten the bolt with a
torque of 30 Nm.
5. Place and tighten a lock nut (C) at the bolt.
6. Re-lubricate the running surfaces of the
wheels with Bel-Ray No-Tox HD Grease
(62270, 62280) or equal.
7.8.6 Replace the curve plate - bottom side
Uninstall the curve plate
1. Remove the side covers (A).
2. Remove the curve plate (A).
Note
Pay attention to the torque.
A
B
C
A
A
A
