Description
28 UM-PRORUNNER_Mk5-1.2-EN-US
The machine works according to a continuous principle in which the machine runs
nonstop.
However the machine can be used in start/stop mode. To set up the machine for start/stop
mode you must consult Qimarox for the required specifications.
The following sensors must be installed on the machine:
/i
4.2.1 Product infeed
Products must always be fed into the machine one by one within the software specified
time frame. This affects the infeed speed and acceleration. For specifications, refer to the
machine layout drawing.
The available infeed time depends on:
• The speed of the product carriers.
• The dimensions of the product carriers.
• The dimensions of the products.
• The speed of the conveyors.
B3 Start time frame sensor
B8 Sensor for checking presence of product on the outfeed
B9 Sensor for checking if product has left the outfeed (on falling edge)
Sensor
code
Sensor name Refer to section
S1 Supply conveyor sensor (not supplied by Qimarox) 4.2.1
B7 End of infeed conveyor sensor 4.2.1
B1 Product release sensor 4.2.1; 4.2.3
B3 Start time frame sensor 4.2.4
B8 Sensor for checking presence of product on the outfeed 4.2.4
B9 Sensor for checking if product has left the outfeed (on falling
edge)
4.2.4
Note
The description and working principle of the sensors applies to the infeed/out-
feed conveyor on the machine. When infeed or outfeed takes place at several
levels, more sensors are required. Refer to the machine layout drawing.
