Qimarox PRORUNNER Mk5 User Manual

UM-PRORUNNER_Mk5-1.2-EN-US 57
Installation
6.6 Installing the supply conveyor
6.6.1 Procedure
1. Determine the position of the conveyor to
be installed. If the conveyor is supplied by
Qimarox, the position can be found on the
supplied drawings.
2. If required, drill holes if the conveyor is to
be installed outside the slotted holes
already provided.
3. Attach the conveyor to the frame (A) at the
corresponding slotted holes.
DANGER
Do not drill any extra cable holes in the shaded part (A) with a diameter larger
than 8 mm, unless they are sealed again before use. This is important to make
sure there is no risk of body parts becoming jammed in the machine. Always
observe national and local legislation and regulations with regard to health and
safety.
A
A
