Qimarox PRORUNNER Mk5 User Manual

Exploded views of product conveyors
164 UM-PRORUNNER_Mk5-1.2-EN-US
16.6.2 Multi belt infeed mounting materials
/i
Drive section Package B-02
Item no.: 1004000
Quan-
tity
Article number Description (mounting mat.) Notes
4 1000897 Hexagonal stud bolt 8.8Elvz M6 x 20
18 1000209 Hexagonal stud bolt 8.8Elvz M8 x 16
6 1002261 Hexagonal stud bolt 8.8Elvz M8 x 75
4 1000193 Hexagonal stud bolt 8.8Elvz M10 x 20
4 1000194 Hexagonal stud bolt 8.8Elvz M10 x 25
4 1000194 Hexagonal stud bolt M10 x 25
2 1002259 Cylinder screw BZK M3 x 10
70 1000895 Countersunk bolt 8.8 Elvz M6 x 12
5 1002633 Adjusting screw BZK Elvz M5 x 10
56 1001658 Circlip Steel A12
6 1001104 Circlip Steel A25
28 1002263 Circlip Steel J28
2 1002257 Spring washer Elvz M3
4 1000174 Spring washer Elvz M6
24 1000398 Spring washer Elvz M8
12 1000172 Spring washer Elvz M10
4 1000147 Flat washer Elvz M10
3 1003104 Wedge steel 8 x 7 x 25
1 1003932 Cylinder screw BZK M4 x 20
1 1001676 Spring washer Elvz M4
4 1000125 Nut M10
1 1000325 Nut M5
