UM-PRORUNNER_Mk5-1.2-EN-US 137
Exploded views of frame parts
15.6.1 Assembly section parts list - 1
/i
Assembly Package C-01-1
Item no. 1000144
Pos Article number Description (parts) Notes
A Drive section
B Tensioning section
C Centre section
D Trolley
E 1000097 Chain 1" 16B-1 7 links
1000702 Chain 1" 16B-1 1 link
F 1000154 Closing link 16B-1
G 1000215 Assembly of guide standard
1000821 Guide HD assembly
H 1000130 Spacer 30 x 42 x 0.5 mm
1000224 Spacer 35 x 45 x 0.5 mm
I 1000116 Clamp adjusting ring 30 mm
1000223 Clamp adjusting ring 35 mm
J 1000713 Fork St. 75 8x L = 473 mm
1000714 Fork St. 75 8x L = 473 mm
1000715 Fork HD St. 75 6x L = 523 mm
1000716 Fork HD St. 75 6x L = 473 mm
1000751 Fork HD St. 75 8x L = 673 mm
1000943 Fork St. 75 10x L = 673 mm
1000982 Fork St. 100 8x L = 723 mm
1001095 Fork St. 75 6x L = 473 mm
1001168 Fork St. 75 6x L = 473 mm
1001212 Fork HD St. 75 8x L = 723 mm
1001213 Fork HD St. 75 8x L = 743 mm
1001259 Fork St. 55 10x L = 473 mm
1001370 Fork HD St. 75 6x L = 473 mm
1001635 Fork HD St. 75 10x L = 523 mm
1002567 Fork St. 75 6x L = 625 mm
M 1000004 Cover PRmk5 rear 5 mm R77
1000738 Cover PRmk5 rear 0.75 mm R77
1001023 Cover PRmk5 rear 5 mm R77 Mov.
1001402 Cover PRmk5 rear 0.75 mm R77
1001650 Cover PRmk5 rear 0.75 mm R77
