Qimarox PRORUNNER Mk5 User Manual

Exploded views of frame parts
128 UM-PRORUNNER_Mk5-1.2-EN-US
15.4.1 Tensioning section parts list 1/2
/i
Tensioning section Package A-01-1
Item no. 1000142
Pos Quan-
tity
Item
number
Description (parts) Notes
1 1001606 Box 600 x 350 x 120 mm
A 1 1000815 Tensioning section L = 1475 mm
1 1000818 Tensioning section L = 1725 mm
1 1000854 Tensioning section L = 1975 mm
B 1 1000156 Clamping bolt M20 x 200 mm
C 1 1000087 Cylinder head screw M12 x 12.0 mm
D 1 1000157 Lug
E 1 1000078 Guide plate centre z = 76
F 1 1000185 Guide plate spacer sleeve
G 1 1000122 Plastic ring 50 x 61 x 1 mm
H 1 1000165 Adjusting ring 50 mm
I 1 1000863 Sprocket 1" Z=76 with slide bearing
M1 1 1000049 Tie rod attachment
M2 1 1000951 Tie rod curve frame left
M3 1 1000169 Tie rod curve frame right
P1 1 1000181 Foot right
P2 1 1000824 Foot left
Q 4 1000196 Hexagonal stud bolt M16 x 100 mm
R1 1 1000872 Foot spacer right
R2 1 1000871 Foot spacer left
S 4 1000164 Adjustment anchor hook line H = 150 mm
T 6 1000692 Shield clamping bracket 0.8 mm
6 1000113 Shield clamping bracket 1.5 mm
