Qimarox PRORUNNER Mk5 User Manual

UM-PRORUNNER_Mk5-1.2-EN-US 135
Exploded views of frame parts
15.5.2 Centre section mounting materials
/i
Centre section Package C-02
Item no.: 1000144
Quantity Article number Description (mounting mat.) Notes
1 1001606 Box 600 x 350 x 120 mm
8 1000134 Pop rivet Al 6.4 x 12
6 1000197 Hexagonal stud bolt M6 x 25
6 1000148 Washer M6
10 1000174 Spring washer M6
8 1000177 Countersunk hexagonal socket bolt M6 x 16
24 1000172 Spring washer M10
12 1000125 Nut M10
20 1000147 Washer M10
4 1000193 Hexagonal stud bolt M10 x 20
16 1000194 Hexagonal stud bolt M10 x 25
4 1000195 Hexagonal stud bolt M10 x 30
4 1000149 Washer M8
2 1000050 Locknut M8
4 1001175 Hexagonal stud bolt M8 x 20
4 1000208 Hexagonal stud bolt M8 x 12
2 1000209 Hexagonal stud bolt M8 x 16
4
*
* Assemble these parts at a later stage
1000973 M6
14 * 1000167 M6 x 16
