Qimarox PRORUNNER Mk5 User Manual

UM-PRORUNNER_Mk5-1.2-EN-US 147
Exploded views of frame parts
15.8.1 Trolley parts list and mounting materials
/i
/i
Trolley
Item no.
Pos Quan-
tity
Item
number
Description (parts) Notes
A 1 1000076 Frame trolley PRmk5 galv. 3 mm
B 1 1000043 Shaft trolley PRmk5 ø15 L = 81.4 mm
C 2 1000098 Trolley HD chain mounting
D 4 1000186 Spacer sleeve for closing link
E 9 1000672 Ball bearing ø = 50x30
F 18 1000153 Flat washer galv. M14
G 10 1000162 Starlock without cover ø15 mm
H 2 1000120 Collar bearing Iglidur G ø30 x 20 mm
I 2 1000139 Trolley rubber profile L = 90 mm
J 2 1000209 Hexagonal stud bolt 8.8 galv. M8 x 16
K 2 1000398 Spring washer galv. M8
L 2 1000097 Chain 16B-1 RKK 7 link =177.8 mm
M 2 1000155 Closing link 16B-2 RKK
N 2 1000154 Closing link 16B-1 RKK
O 4 1000208 Hexagonal stud bolt 8.8 galv. M6 x 12
P 4 1000148 Flat washer galv. M6 x 12
Trolley HD
Item no.
Pos Quan-
tity
Item
number
Description (parts) Notes
A 1 1000077 Frame trolley PRmk5 HD galv.
B 1 1000043 Shaft trolley PRmk5 ø15 L = 81.4 mm
C 2 1000098 Trolley HD chain mounting
D 4 1000186 Spacer sleeve for closing link
E 9 1000191 Wheel GSPO50/15K
F 18 1000153 Flat washer galv. M14
G 10 1000162 Starlock without cover ø15 mm
H 2 1000121 Collar bearing sintered bronze finish ø30 x 20 mm
I 2 1000139 Trolley rubber profile L = 90 mm
J 2 1000209 Hexagonal stud bolt 8.8 galv. M8 x 16
K 2 1000398 Spring washer galv. M8
