Qimarox PRORUNNER Mk5 User Manual

Exploded views of frame parts
138 UM-PRORUNNER_Mk5-1.2-EN-US
15.6.2 Assembly section parts list - 2
/i
K 1001228 Gooseneck 150 mm
1001229 Gooseneck 100 mm
1001230 Gooseneck 75 mm
Assembly Package C-01-1
Item no. 1000144
Pos Article number Description (parts) Notes
Assembly section - 2
Item no. 1000144
Pos Article number Description (parts) Notes
L 1000006 Cover PRmk5 rear 5 mm 781 x H 595 plastic Red
MJ21
L 1000007 Cover PRmk5 rear 5 mm 781 x H 845 plastic Red
MJ21
L 1000008 Cover PRmk5 rear 5 mm 781 x H 1095 plastic Red
MJ21
L 1000009 Cover PRmk5 rear 5 mm 781 x H 521 plastic Red
MJ21
L 1000010 Cover PRmk5 rear 5 mm 781 x H 871 plastic Red
MJ21
L 1000011 Cover PRmk5 rear 5 mm 781 x H 958 plastic Red
MJ21
L 1000012 Cover PRmk5 rear 5 mm 781 x H 458 plastic Red
MJ21
L 1000013 Cover PRmk5 rear 5 mm 781 x H 958 plastic Red
MJ21
L 1000014 Cover PRmk5 rear 5 mm 781 x H 770 plastic Red
MJ21
L 1000855 Cover PRmk5 rear 0.8 mm 781 x H 571 steel,
RAL3020
L 1001196 Cover PRmk5 rear 0.75 mm 982 x H 595 steel,
RAL3020
L 1001294 Cover PRmk5 rear 5 mm 781 x H 981 plastic Green
PW18
L 1001392 Cover PRmk5 rear 0.75 mm span 793 x H 770, S235 SV
RAL3020
L 1001393 Cover PRmk5 rear 0.75 mm 781 x H 759, S235 SV
RAL3020
L 1001394 Cover PRmk5 rear 0.75 mm 781 x H 1009, S235 SV
RAL3020
