UM-PRORUNNER_Mk5-1.2-EN-US 151

Exploded views of product conveyors

16.2.1 RollerDrive infeed parts list

Drive section Package B-01

Item no. 1003924

Pos Quan

tity

Item

number

Description (parts) Notes

A 1 1003060 Conveyor bracket PRmk5

B 1 1003093 Basis conveyor frame PRmk5

C 2 1003072 Fastening reflector PRmk5

D 1 1002242 Reflector

E 8 1000968 ROL 50 ELVZ IL 560

F 1 1000707 RollerDrive EC310 16 : 1 L=560 mm

G 8 1000133 PolyVee belt PU, 2-v. st. 75

H 4 1003058 Support standard

4 1004269 Support MK5-XL

I 0.5 1004305 Conveyor supports PRmk5 400

J 1 1003094 Fastening rol PRmk5

K 1 1000058 DriveControl 20

L 1 xxxx Coupling piece

M 1 1002097 Photocell

N 1 1004325 End stop L=400 mm

1 1004326 End stop L=600 mm

O 1 1003096 Rol support PRmk5
