Qimarox PRORUNNER Mk5 User Manual

Exploded views of frame parts
126 UM-PRORUNNER_Mk5-1.2-EN-US
15.3.1 Motor reductor (option) section parts list
/i
15.3.2 Motor reduction (option) section mounting materials
/i
Motor reductor section Package
Item no.
Pos Quan
tity
Item
number
Description (parts) Notes
A 1 1001183 Moment arm support KA87 PRmk5
B 2 1001010 Nut plate moment arm KA87
PRmk5
C 1 1000976 Bearing block PASE 60N
D 1 1001007 Bearing block mounting Prmk5
D1 2 1001008 Filling plate bearing block Prmk5
PASE 60N
E 2 1001299 Drive spindle PRmk5 KA87
F 2 1001014 Key steel 18 x 11 x 125 mm
G 3 1001011 Reductor KA87 / TAM90 I = 147,32
H 3 1001012 Sprocket 1" ø90 ELVZ Z = 76 mm
I 3 1000803 Clamping bush DX ø60/ø90 L = 72 mm
Motor reduction section Package
Item no.:
Quan-
tity
Article number Description (mounting mat.) Notes
4 1001015 Hexagonal stud bolt M16 x 70
4 1000151 Washer M16
4 1000883 Spring washer M16
1 1001016 Hexagonal stud bolt M24 x 160
1 1001019 Washer M24
1 1001020 Spring washer M24
1 1001021 Hexagonal nut M24
6 1001022 Hexagonal stud bolt M12 x 35
6 1000173 Spring washer M12
