Qimarox PRORUNNER Mk5 User Manual

Exploded views of frame parts
124 UM-PRORUNNER_Mk5-1.2-EN-US
15.2.2 Drive section mounting materials
/i
Drive section Package B-02
Item no.: 1000143
Quan-
tity
Article number Description (mounting mat.) Notes
6 1000148 Washer M6
10 1000174 Spring washer M6
8 1000172 Spring washer M10
6 1000175 Spring washer M8
18 1000149 Washer M8
6 1000050 Locknut M8
6 1000197 Hexagonal stud bolt M6 x 25
2 1001175 Hexagonal stud bolt M8 x 20
8 1000193 Hexagonal stud bolt M10 x 20
2 1000198 Hexagonal stud bolt M8 x 25
6 1000209 Hexagonal stud bolt M8 x 16
2 1000974 Hexagonal stud bolt M8 x 30
8 1000173 Spring washer M12
8 1000201 Hexagonal stud bolt M12 x 30
8 1000202 Hexagonal stud bolt M12 x 40
4 1000975 Hexagonal stud bolt M21 x 45
8 1000150 Washer M12
8 1000134 Pop rivet Al 6.4 x 12
4 1000208 Hexagonal stud bolt M6 x 12
4
*
* Assemble these parts at a later stage
1000973 Locknut M6
14 * 1000167 Taptite round head cylinder screw M6 x 16
