UM-PRORUNNER_Mk5-1.2-EN-US 123
Exploded views of frame parts
15.2.1 Drive section parts list
/i
Drive section Package B-01
Item no. 1000143
Pos Quan
tity
Item
number
Description (parts) Notes
1 100060 Box 185 x 125 x 90 mm
A 1 1001346 Drive section L = 1475 mm
1 1001347 Drive section L = 1725 mm
1 1001348 Drive section L = 1975 mm
B 2 1000099 Chain guide L = 800 mm
2 1000107 Chain guide L = 1050 mm
2 1000100 Chain guide L = 1300 mm
C 3 1000214 Trolley
3 1000820 Trolley HD
D 1 Drive, see layout drawing in manual
E 1 1000187 Filling plate R77 3 mm
F 1 1000188 Filling plate R57
G 1 1000189 Filling plate R67
H 1 1000111 Sprocket 1" Z=76 clamping bush hole D = 60 mm
1 1000112 Sprocket 1" Z=76 clamping bush hole D = 65 mm
1 1001012 Sprocket 1" Z=76 clamping bush hole D = 90 mm
J 1 1000875 Chain 16B1
K 1 1000154 Closing link 16B1
L 1 1000095 Baffle top
M 1 1000056 Curve frame top
N 2 1000081 Hoisting eye 12 mm
O 6 1000692 Shield clamping bracket 0.8 mm
6 1000113 Shield clamping bracket 1.5 mm
P 1 1000736 Cable guide side L = 1275 mm
1 1000752 Cable guide side L = 1525 mm
1 1000756 Cable guide side L = 1775 mm
Q 1 1000093 Cable guide centre L = 790 mm
1 1000088 Cable guide centre L = 1040 mm
1 1000089 Cable guide centre L = 1290 mm
R Assemble these parts at a later
stage
