Qimarox PRORUNNER Mk5 User Manual

Exploded views of frame parts
144 UM-PRORUNNER_Mk5-1.2-EN-US
15.7.1 Guide parts list and mounting materials
/i
/i
/i
Guide
Item no.
Pos Quan-
tity
Item
number
Description (parts) Notes
A 1 1000135 Guide PRmk5 galv.
B 4 1000190 Wheel PP 125x24/10-28G-SK
C 4 1000219 Fitted screw, steel (M8) ø10 x 30
D 4 1000220 Low hexagonal nut galv. 8 M8
E 4 1000221 Spacer 1 mm steel ø10 * ø16
F 1 1000116 Clamp adjusting ring steel ø30
G 2 1000130 Spacer, steel 0.5 mm ø30 * ø42
H 1 1000200 Hexagonal stud bolt 8.8 galv. M12 x 25
I 1 1000173 Spring washer galv. M12
Guide HD
Item no.
Pos Quan-
tity
Item
number
Description (parts) Notes
A 1 1000218 Guide PRmk5 HD galv.
B 4 1000190 Wheel PP 125x24/10-28G-SK
C 4 1000219 Fitted screw, steel (M8) ø10 x 30
D 4 1000220 Low hexagonal nut galv. 8 M8
E 4 1000221 Spacer 1 mm steel ø10 * ø16
F 1 1000223 Clamp adjusting ring steel ø35
G 2 1000224 Spacer, steel 0.5 mm ø35 * ø45
H 1 1000202 Hexagonal stud bolt 8.8 galv. M12 x 40
I 1 1000173 Spring washer galv. M12
Guide stainless steel
Item no.
Pos Quan-
tity
Item
number
Description (parts) Notes
A 1 1000765 Guide PRmk5 stainless steel galv.
B 4 1000190 Wheel PP 125x24/10-28G-SK
C 4 1001221 Fitted screw, stainless steel (M8) ø10 x 30
