Exploded views of frame parts
134 UM-PRORUNNER_Mk5-1.2-EN-US
15.5.1 Centre section parts list
/i
Centre section Package C-01
Item no. 1000144
Pos Quan
tity
Item
number
Description (parts) Notes
1 1001606 Box 600 x 350 x 120 mm
A 1 1000800 Centre section L = 1250 mm
1 1000805 Centre section L = 1950 mm
1 1000810 Centre section L = 1350 mm
B 2 1000101 Chain guide profile L = 1250 mm
2 1000102 Chain guide profile L = 1950 mm
2 1000813 Chain guide profile L = 1350 mm
C 6 1000692 Shield clamping bracket 0.8 mm
6 1000113 Shield clamping bracket 1.5 mm
D 1 1000801 Cable guide side L = 1050 mm
1 1000806 Cable guide side L = 1750 mm
1 1000812 Cable guide side L = 1350 mm
E 1 1000090 Cable guide centre L = 2140 mm
1 1000102 Cable guide centre L = 1940 mm
1 1000811 Cable guide centre L = 1340 mm
E 1 1000692 Shield clamping bracket 0.8 mm
1 1000113 Shield clamping bracket 1.5 mm
F1 2 1000117 Wheel guide coupling plate
F2 2 1000118 Inner column coupling plate
F3 1000119 Outer column coupling plate
F4 2 1000129 Nut plate M10 st. 50 mm
G * 1 1000214 Trolley mounting assembly
1 1000820 Trolley HD mounting assembly
J Assemble these parts at a later stage
