Exploded views of product conveyors
16.9.2 Gravity wheel outfeed mounting materials
/i
Drive section Package B-02
Item no.: 1004001
Quan-
tity
Article number Description (mounting mat.) Notes
24 1000209 Hexagonal stud bolt 8.8Elvz M8 x 16
6 1002261 Hexagonal stud bolt 8.8Elvz M8 x 75
4 1000193 Hexagonal stud bolt 8.8Elvz M10 x 20
4 1000197 Hexagonal stud bolt 8.8Elvz M10 x 25
4 1002259 Cylinder screw BZK M3 x 10
21 1002271 Cylinder screw BZK M5 x 10
4 1002257 Spring washer Elvz M3
24 1000398 Spring washer Elvz M8
8 1000172 Spring washer Elvz M10
21 1000396 Spring washer Elvz M5
1 1003932 Cylinder screw BZK M4 x 20
1 1001676 Spring washer Elvz M4
4 1000125 Nut M10
2 1000325 Nut M5
