UM-PRORUNNER_Mk5-1.2-EN-US 25
Description
4 Description
4.1 Overview of parts
4.1.1 General overview
A Supply conveyor (not supplied by Qimarox)
B Infeed conveyor (optional)
C Lift column
DMotor
E Outfeed conveyor (optional)
F Output conveyor (not supplied by Qimarox)
G Product carrier
The PRORUNNER Mk5 is designed for the vertical transport of products. This vertical
transport unit (or product lift) consists of a lift column, one or more product carriers and.
depending on the purchased configuration, a dosing belt, output belt and shielding.
The vertical transport of products can be upwards as well as downwards, and depending
on the configuration, even a combination of the two. The lift is always installed as part of a
larger transport system in which products are automatically transported to the product lift
as well as away from the product lift.
A
E
F
B
G
C
D
