Qimarox PRORUNNER Mk5 User Manual

Exploded views of product conveyors
158 UM-PRORUNNER_Mk5-1.2-EN-US
16.4.2 Gravity roller infeed mounting materials
/i
Drive section Package B-02
Item no.: 1003999
Quan-
tity
Article number Description (mounting mat.) Notes
2 1000208 Hexagonal stud bolt 8.8Elvz M6 x 12
17 1000209 Hexagonal stud bolt 8.8Elvz M8 x 16
18 1001332 Hexagonal stud bolt 8.8Elvz M8 x 60
10 1000193 Hexagonal stud bolt 8.8Elvz M10 x 20
2 1000387 Hexagonal stud bolt 8.8Elvz M10 x 55
4 1000194 Hexagonal stud bolt 8.8Elvz M10 x 25
2 1002259 Cylinder screw BZK M3 x 10
2 1002257 Spring washer Elvz M3
2 1000174 Spring washer Elvz M6
35 1000398 Spring washer Elvz M8
16 1000172 Spring washer Elvz M10
1 1003105 Cap RH 50 x 40 black (pos P)
1 1003932 Cylinder screw BZK M4 x 20
1 1001676 Spring washer Elvz M4
4 1000125 Nut M10
1 1000325 Nut M5
