Exploded views of product conveyors

172 UM-PRORUNNER_Mk5-1.2-EN-US

16.9.1 Gravity wheel outfeed parts list

Drive section Package B-01

Item no. 1003929

Pos Quan

tity

Item

number

Description (parts) Notes

A 1 1003060 Conveyor bracket PRmk5

B 4 1003058 Support standard

4 1004269 Support MK5-XL

C 0.5 1004305 Conveyor supports PRmk5 400

D 1 1003087 Fastening photocell PRmk5

E 2 1002097 Photocell

F 1 1003086 Fastening reflector PRmk5

G 2 1002242 Reflector

H 1 xxxx Coupling piece

I 7 1003107 Wheel bracket L = 572

J 7 1003091 C-profile wheel track PRmk5

K 7 1003090 Nutplate 2 x M8 St. 100 PRmk5

L 1 1003089 Bracket wheel track PRmk5

M 1 1003088 Track plate PRmk5
