Qimarox PRORUNNER Mk5 User Manual

Maintenance vertical conveyor
72 UM-PRORUNNER_Mk5-1.2-EN-US
2. Remove the bolt (B).
3. Remove the product carrier (A).
Install the product carrier
1. Install the product carrier.
2. Before switching on the machine, move the product carrier to the upper sprocket
wheel.
7.8.4 Replace the slide bearings of the leveler
Replace slide bearing - front side
1. Open the machine. Refer to section 7.8.1
and follow parts 1 - 4.
2. Remove the adjusting ring (A).
3. Remove the ring (B).
A
B
Tip
Illustrations for installing: see the illustrations above for uninstalling.
B
A
