Qimarox PRORUNNER Mk5 User Manual

UM-PRORUNNER_Mk5-1.2-EN-US 73
Maintenance vertical conveyor
Replace slide bearing - rear side
1. Remove the leveler with the 4 wheels (A)
from the machine.
2. Remove the ring (B).
3. Remove the bearings (A) at front side and
rear side.
Install the guide
1. Install the new bearing on the rear side. Pay attention to the maximum diameter of the
ring.
2. Install the guide on the rear side.
3. Place the new bearing on the front side.
4. Place the ring and the adjusting ring on the front side.
5. Place the product carrier on the front side.
WARNING
Pay attention to ring (B).
B
A
A
A
Tip
Illustrations for installing: see the illustrations above for uninstalling.
