Exploded views of frame parts
148 UM-PRORUNNER_Mk5-1.2-EN-US
/i
L 2 1000097 Chain 16B-1 RKK 7 link =177.8 mm
M 2 1000155 Closing link 16B-2 RKK
N 2 1000154 Closing link 16B-1 RKK
O 4 1000208 Hexagonal stud bolt 8.8 galv. M6 x 12
P 4 1000148 Flat washer galv. M6 x 12
Trolley stainless steel
Item no.
Pos Quan-
tity
Item
number
Description (parts) Notes
A 1 1000757 Frame trolley PRmk5 stainless steel 4 mm
B 1 1000758 Shaft trolley PRmk5 stainless steel ø15 L = 81.4 mm
C 2 1000759 Trolley chain mounting stainless steel
D 4 1000760 Spacer sleeve for closing link stainless
steel
E 9 1000763 Wheel GSPO50/15XK
F 18 1001043 Flat washer stainless steel A2 M14
G 10 1001216 Starlock without cover ø15 mm
H 2 1000764 Collar bearing Iglidur G ø30 x 20 mm
I 2 1000139 Trolley rubber profile L = 90 mm
J 2 1001217 Hexagonal stud bolt stainless steel A2 M8 x 16
K 2 1001218 Spring washer stainless steel A2 M8
L 2 1000770 Chain 16B-1 SY 7 link =177.8 mm
M 2 1000769 Closing link 16B-2 SY Aquaprf
N 2 1000768 Closing link 16B-1 SY Aquaprf
O 4 1001219 Hexagonal stud bolt stainless steel A2 M6 x 12
P 4 1001220 Flat washer stainless steel A2 M6 x 12
Trolley HD
Item no.
Pos Quan-
tity
Item
number
Description (parts) Notes
