Qimarox PRORUNNER Mk5 User Manual

Electrical circuit diagrams
184 UM-PRORUNNER_Mk5-1.2-EN-US
/i
Position Name Amount Article number Discription
-B1 Product release 1 1000932 Inductive proximity switch, IME18-
08BPSZC0K
-B1-W1 1 1001601 Cable, PVC, 1 meter, M12 male 90°+
M12 female 90°, 4-pole
-B7 End of infeed
conveyor
1 1002097 Photoelectric retro-reflex sensor, WL100-
P4400
-B7 1 1002242 Reflector, C42-2
-B7-W1 1 1003307 Cable, PVC, 1 meter, M12 male straight
+ M8 female straight, 4-pole
-B11 Carrier past
infeed
1 1000932 Inductive proximity switch, IME18-
08BPSZC0K
-B11-W1 1 1001601 Cable, PVC, 1 meter, M12 male 90°+
M12 female 90°, 4-pole
-B12 Infeed out posi-
tion
1 1000932 Inductive proximity switch, IME18-
08BPSZC0K
-B12-W1 1 1001601 Cable, PVC, 1 meter, M12 male 90°+
M12 female 90°, 4-pole
-B14 Infeed in posi-
tion
1 1000932 Inductive proximity switch, IME18-
08BPSZC0K
-B14-W1 1 1001601 Cable, PVC, 1 meter, M12 male 90°+
M12 female 90°, 4-pole
-Y1 Infeed to out
position
1 Coil, see mechanical specification
-Y1-W1 1 Prefab cable, PVC, 1 meter, connector
M12 male + MSUD coil C-Form 8 mm
-Y2 Infeed to in
position
1 Coil, see mechanical specification
-Y2-W1 1 Prefab cable, PVC, 1 meter, connector
M12 male + MSUD coil C-Form 8 mm
-U20 T-Couple 1 1003313 T-Coupler 5 Pole Male M12 / 2x 4 Pole
Female M12
-U20-W1 1 1001326 Cable, PVC, 5 meter, M12 male 90°+
M12 female 90°,4-pole
-U2 Connection unit
infeed
1 1003309 Exact12, 8-way, 5-pole, M12
