UM-PRORUNNER_Mk5-1.2-EN-US 193
Electrical circuit diagrams
/i
Position Name Amount Article number Discription
-B3 Start time frame 1 1000932 Inductive proximity switch, IME18-
08BPSZC0K
-B3-W1 1 1001601 Cable, PVC, 1 meter, M12 male 90°+
M12 female 90°, 4-pole
-B8 Product on out-
feed
1 1002097 Photoelectric retro-reflex sensor, WL100-
P4400
-B8 1 1002242 Reflector, C42-2
-B8-W1 1 1003307 Cable, PVC, 1 meter, M12 male straight
+ M8 female straight, 4-pole
-B9 Product left out-
feed
1 1002097 Photoelectric retro-reflex sensor, WL100-
P4400
-B9 1 1002242 Reflector, C42-2
-B9-W1 1 1003307 Cable, PVC, 1 meter, M12 male straight
+ M8 female straight, 4-pole
-B16 Carrier past out-
feed
1 1000932 Inductive proximity switch, IME18-
08BPSZC0K
-B16-W1 1 1001601 Cable, PVC, 1 meter, M12 male 90°+
M12 female 90°, 4-pole
-B17 Outfeed out
position
1 1000932 Inductive proximity switch, IME18-
08BPSZC0K
-B17-W1 1 1001601 Cable, PVC, 1 meter, M12 male 90°+
M12 female 90°, 4-pole
-B19 Outfeed in posi-
tion
1 1000932 Inductive proximity switch, IME18-
08BPSZC0K
-B19-W1 1 1001601 Cable, PVC, 1 meter, M12 male 90°+
M12 female 90°, 4-pole
-Y3 Outfeed to out
position
1 Coil, see mechanical parts list
-Y3-W1 1 Cable, PVC, 1 meter, M12 male + MSUD
Coil C-Form 8mm
-Y4 Outfeed to in
position
1 Coil, see mechanical parts list
-Y4-W1 1 Cable, PVC, 1 meter, M12 male + MSUD
Coil C-Form 8mm
-U21 1 1003313 T-Coupler 5 Pole Male M12 / 2x 4 Pole
Female M12
-U21-W1 1 1001326 Cable, PVC, 5 meter, M12 male 90°+
M12 female 90°,4-pole
-U3 1 1003309 Exact12, 8-way, 5-pole, M12
To Next Page
