Qimarox PRORUNNER Mk5 User Manual

Maintenance vertical conveyor
68 UM-PRORUNNER_Mk5-1.2-EN-US
Uninstall the trolley - part 3
1. Remove the guard (A).
Uninstall the trolley - part 4
1. If the drive does not have a brake, clamp
the sprocket wheel (A) onto the frame (B).
Use the auxiliary tool. The sprocket wheel
must not tilt or turn with respect to the
frame.
DANGER
If the drive does not have a brake, the drive sprocket wheel must be clamped
onto the frame. If the drive sprocket wheel can turn, this may cause injury.
Therefore the auxiliary tool is required. You can order this auxiliary tool through
Qimarox.
Note
Now an auxiliary tool can be
placed to prevent the sprocket
wheel from tilting or turning. Refer
to section Uninstall the trolley -
part 4<Default ¬¹ Font>.
A
B
B
A
