General instrument settings
R&S
®
LCX Series
131User Manual 1179.2260.02 ─ 02
5. Now you can send the file to your local service department.
9.11 Update device
The update functionality enables you to update the firmware of the instrument. Using
the USB interface at the front panel, you can provide the installation file for the update.
Required equipment
●
Software:
Software update file RS_LCRxxx_Software_<version>.zip
We recommend that you use the latest software version, available on the product
page at www.rohde-schwarz.com/firmware/lcr.
●
Hardware:
USB memory stick with enough free space to save the update file.
The memory stick does not need to be bootable and previous data on the stick is
not affected. Several update files can reside on the stick in parallel. During update
procedure, the stick is not modified by the instrument.
How to: see Chapter 9.11.2, "Updating the instrument software", on page 132
9.11.1 Update device settings
With the update functionality, you can install a new version of the instrument software.
To provide the update, use a USB memory stick for file transfer.
Access:
1. Press the [settings] key at the front panel.
2. In the "Device" tab, select "Update Device".
The update device dialog provides access to the memory to upload the instrument
software file. The file manager dialog enables you to select the file directory and
provides information on the currently installed software version.
UPDATE......................................................................................................................132
