R&S LCX Series User Manual

Getting started
R&S
®
LCX Series
26User Manual 1179.2260.02 ─ 02
4.2.1 Front panel tour
1 2 3 4 5 6
79
10
11
8
Figure 4-4: R&S LCX front panel
1 = Basic display keys, see "Basic display keys" on page 27
2 = Touchscreen display, see Chapter 4.2.1.1, "Touchscreen display", on page 26
3 = Navigation controls, see "Navigation controls" on page 27
4 = Function keys, see "Function keys" on page 28
5 = Setting keys, see "Settings keys" on page 28
6 = Measurement control keys, see "Measurement control keys" on page 28
7 = BNC measurement connectors, see "L CUR, L POT, H CUR, H POT" on page 29
8 = Measurement mode keys, see "Measurement mode keys" on page 28
9 = Ground connector, see "Ground socket" on page 29
10 = POWER key, see "POWER On/Standby key" on page 29
11 = USB host connector
4.2.1.1 Touchscreen display
The color TFT touchscreen at the front panel is the graphical user interface. It shows
the measurement readings, status information and settings, and provides access to
settings dialogs.
Instrument tour
