R&S LCX Series User Manual

General instrument settings
R&S
®
LCX Series
116User Manual 1179.2260.02 ─ 02
9.1.3 Data and file types
The R&S LCX distinguishes the files according to their extensions; each type of file is
assigned a specific file content and also a specific file extension. The extension is pre-
defined, e.g. you can save and load files with logging data only as *.csv files.
Table 9-1: Overview of data and file types
Data type File extension Description
Binning
*.csv
See Chapter 8.8.5, "Binning",
on page 102
Documentation
*.pdf
Getting Started manual, and OSA (Open
Source Acknowledgement).
Logging
*.csv
See Chapter 8.8.3, "Logging",
on page 94
Screenshot
See Chapter 9.4, "Screenshot",
on page 119
Settings
*.savrcl
See Chapter 9.12, "Save/recall",
on page 133
Service
*.rsd
Device information
*.rsd
See Chapter 9.10, "Device information",
on page 129
Firmware
*.rsu
See Chapter 9.11, "Update device",
on page 131
Licenses
*.xml
See Chapter 9.9, "Licenses",
on page 126
9.2 Interfaces
The R&S LCX provides a LAN, a USB and, optionally a GPIB (IEC/IEEE) bus interface
for controlling the instrument remotely.
In the "Interfaces" menu, you can access the settings dialogs for configuring the gen-
eral network environment and specific identification parameters of the instrument.
The following description introduces the access to the interface settings. For detailed
information on connection, protocols and additional configurations, see Chapter 10,
"Network operation and remote control", on page 139. This section also covers the set-
ting parameter descriptions and step-by-step instructions for setting up remote control
for each interface.
Interfaces
