Network operation and remote control

R&S

LCX Series

149User Manual 1179.2260.02 ─ 02

Table 10-4: Assignment of the bits used in the questionable status register

Bit No. Meaning

I-BIAS OV

Ext. V-BIAS OV

I-BIAS Analog FB Sat

LCUR outamp DC OV

LCUR outamp OT

Outamp disabled

LF-TIA OV

IQ-Mixer OV

CALibrating

9 Resistance overrange

OCP

EXPCalibration

12 to 14 Not used

15 This bit is always 0

See the schematic representation Figure 10-2.

10.3 Remote access settings

This section outlines the settings required for accessing and configuring the provided

remote control interfaces. It includes the interface settings, access addresses, and the

access using controller devices.

10.3.1 Network settings

The Ethernet (LAN) connectivity enables you, to access the R&S LCX remotely. Provi-

ded the corresponding rights are assigned, you can use these interfaces for remote

control and data transfer from a controller PC.

This section introduces the settings for remote control connections of the interfaces

provided by the R&S LCX.

Access:

1. Press the [settings] key at the front panel.

2. In the device settings menu, select "Interfaces".

3. Select "Network".

Remote access settings

R&S LCX Series User Manual
