R&S LCX Series User Manual

Remote control commands
R&S
®
LCX Series
177User Manual 1179.2260.02 ─ 02
SHORt
Sets the measurement time ≤.015 s.
MEDium
Sets the measurement time ≤0.100 s.
LONG
Sets the measurement time ≤0.500 s.
DEFault
Uses the default setting "SHORt".
Example: See Example "Setting key parameters" on page 176.
Manual operation: See "Measurement Speed" on page 76
CURRent[:LEVel]
<Current Level>
CURRent[:LEVel]? <Current Level>
Sets the test signal current in RMS (root mean square).
Parameters for setting and query:
<Current Level> Range: 0.0001 A to 0.2 A
Default unit: A
Example: See Example "Setting key parameters" on page 176.
Manual operation: See "Level: / [Level]" on page 71
FREQuency[:CW] <Test Signal Frequency>
Sets the frequency of the test signal.
Parameters:
<Frequency> float
Range:
4 to 300 * 10
3
(depends on instrument model and
options)
*RST: 1E+3 Hz
Default unit: Hz
Example: See Example "Setting key parameters" on page 176.
Manual operation: See "Frequency: / [Freq.]" on page 71
VOLTage[:LEVel] <Voltage Level>
Sets the test signal voltage in RMS (root mean square).
Parameters:
<Voltage Level> <numeric>
Sets the value.
MIN | MINimum
Queries the lower limit of the signal level.
Test signal commands
