R&S LCX Series User Manual

Measurement basics
R&S
®
LCX Series
49User Manual 1179.2260.02 ─ 02
Table 5-2: Resistance measurement parameters
Parameter Designation and unit
Rs-X series resistance (Ω) - reactance (Ω)
Rp-B parallel resistance (Ω) - susceptance (Ω)
Rdc DC current resistance (Ω) - reactance (Ω)
G-B
*)
conductance (S) - susceptance (Ω)
Z-Θr
*)
impedance (Ω) - phase angle (rad)
Z-Θd
*)
impedance (Ω) - phase angle (°)
Y-Θr
*)
admittance (S) - phase angle (rad)
Y-Θd
*)
admittance (S) - phase angle (°)
*)
selectable as second measurement parameter pair
Table 5-3: Capacitor measurement parameters
Parameter Designation and unit
Cs-Q serial capacitance (F) - quality factor
Cs-D serial capacitance (F) - dissipation factor
Cs-Rs serial capacitance (F) - serial resistance (Ω)
Cp-Q parallel capacitance (F) - quality factor
Cp-D parallel capacitance (F) - dissipation factor
Cp-Rp parallel capacitance (F) - serial resistance (Ω)
Cp-G parallel capacitance (F) - conductance (S)
G-B
*)
conductance (S) - susceptance (Ω)
Z-Θr
*)
impedance (Ω) - phase angle (rad)
Z-Θd
*)
impedance (Ω) - phase angle (°)
Y-Θr
*)
admittance (S) - phase angle (rad)
Y-Θd
*)
admittance (S) - phase angle (°)
*)
selectable as second measurement parameter pair
Table 5-4: Inductor measurement parameters
Parameter Designation and unit
Ls-Q serial inductance (H) - quality factor
Ls-D serial inductance (H) - dissipation factor
Ls-Rs serial inductance (H) - serial resistance (Ω)
Lp-Q parallel inductance (H) - quality factor
Lp-D parallel inductance (H) - dissipation factor
Impedance measurement parameters of the R&S LCX
