Converters HCS02, HCS03,
HCS04
Product
Series
Type
current Design
Supported as of firmware ver‐
sion
HCS02.1E
- W0012 - A-03- LNNN MPH-02VRS; MPB-02VRS
- W0012 - A-03- NNNN MPH-02VRS; MPB-02VRS
- W0012 - A-03- NNNV MPH-02V20; MPB-02V20
- W0028 - A-03- LNNN MPH-02VRS; MPB-02VRS
- W0028 - A-03- NNNN MPH-02VRS; MPB-02VRS
- W0028 - A-03- NNNV MPH-02V20; MPB-02V20
- W0028 - S-03- NNNN MPH-02VRS; MPB-02VRS
- W0054 - A-03- LNNN MPH-02VRS; MPB-02VRS
- W0054 - A-03- NNNN MPH-02VRS; MPB-02VRS
- W0054 - A-03- NNNV MPH-02V20; MPB-02V20
- W0070 - A-03- LNNN MPH-02VRS; MPB-02VRS
- W0070 - A-03- NNNN MPH-02VRS; MPB-02VRS
- W0070 - A-03- NNNV MPH-02V20; MPB-02V20
HCS03.1E
- W0070 - A-05- LNBV MPH-02VRS; MPB-02VRS
- W0070 - A-05- LNNV MPH-02V11; MPB-02V11
- W0070 - A-05- NNBV MPH-02VRS; MPB-02VRS
- W0070 - A-05- NNNV MPH-02V11; MPB-02V11
- W0070 - A-15- PSPV MPH-02VRS; MPB-02VRS
- W0100 - A-05- LNBV MPH-02VRS; MPB-02VRS
- W0100 - A-05- LNNV MPH-02V11; MPB-02V11
- W0100 - A-05- NNBV MPH-02VRS; MPB-02VRS
- W0100 - A-05- NNNV MPH-02V11; MPB-02V11
- W0150 - A-05- LNBV MPH-02VRS; MPB-02VRS
- W0150 - A-05- LNNV MPH-02V11; MPB-02V11
- W0150 - A-05- NNBV MPH-02VRS; MPB-02VRS
- W0150 - A-05- NNNV MPH-02V11; MPB-02V11
- W0210 - A-05- LNBV MPH-02VRS; MPB-02VRS
- W0210 - A-05- LNNV MPH-02V11; MPB-02V11
- W0210 - A-05- NNBV MPH-02VRS; MPB-02VRS
- W0210 - A-05- NNNV MPH-02V11; MPB-02V11
HCS04.1E
- F0500 - A-05- NNBV MPH-04V10; MPB-04V10
- W0500 - A-05- NCBV MPH-04V10; MPB-04V10
- W0500 - A-05- NNBV MPH-04V10; MPB-04V10
