F4 Fuse of contactor control X34 (see Project Planning Manual "Rexroth
IndraDrive Supply Units and Power Sections")
1) Control of K1, if A10 is not used
2) Drive enable (via input at control section or via master communica‐
tion); see also parameter "P-0-4028, Device control word"
A10 Emergency stop relay (example of circuit)
Bb1 Readiness for operation of supply unit
Bb Readiness for operation of drive controllers (see control section X31.1
and X31.2)
K1 Mains contactor
K4 Control of drive enable
L, N AC supply mains contactor
S1 Emergency stop
S4 Power Off
S5 Power On
S11, S12 Safety door monitor
Fig.9-15: Control Circuit Without DC Bus Short Circuit (ZKS) for HMV01.1R
Supply Units Without Integrated Mains Contactor
Observe Off delay and pick-up delay of K1!
Off delay K1:
Select K1 mains contactors with an Off delay shorter than the On
delay t
d_on
of the DC bus short circuit device. Otherwise, the DC
bus short circuit device switches on with applied mains voltage
and causes tripped fuse (F1) or damage to the supply unit.
Circuits for overvoltage protection increase the Off delay. Ob‐
serve the data of the selected mains contactor!
Pick-up delay K1:
Select K1 mains contactors with a pick-up delay of less than
100 ms. Otherwise, the error message F2835 will be generated.
